Sub-models place to post your settings

Discussion in 'xLights (Nutcracker)' started by Benslights, Nov 17, 2018.

  1. Benslights

    Benslights Dedicated Elf Global Moderator

    Joined:
    May 2, 2010
    Messages:
    2,573
    Likes Received:
    219
    Location:
    Elderslie
    Find Me On:
  2. OP
    OP
    Benslights

    Benslights Dedicated Elf Global Moderator

    Joined:
    May 2, 2010
    Messages:
    2,573
    Likes Received:
    219
    Location:
    Elderslie
    Find Me On:
    boscoyo 36 pixel snow flake



    flake wiring.PNG


    flake sub-models.PNG


    arm1 6,2-5
    arm2 12,8-11
    arm3 18,14-17
    arm4 24,20-23
    arm5 30,26-29
    arm6 36,32-35

    LawrenceDriveLights likes this.
  3. OP
    OP
    Benslights

    Benslights Dedicated Elf Global Moderator

    Joined:
    May 2, 2010
    Messages:
    2,573
    Likes Received:
    219
    Location:
    Elderslie
    Find Me On:
    90 pixel star


    90 pixel star.PNG

    star sub-model.PNG star1 1-20
    star2 21-50
    star3 51-90

  4. djgra79

    djgra79 My name is Graham & I love flashing lights! Generous Elf

    Joined:
    Dec 27, 2011
    Messages:
    1,260
    Likes Received:
    402
    Location:
    Cranbourne West
    Find Me On:
    I've got a few submodels and a singing face on the Boscoyo Spiderweb.
    I must admit I didn't create most of these, as I got it from another user from Facebook, however I have added the snowflake sections, so that the web can be used again during Christmas as a giant snowflake (including a singing face.)
    What I have done is added the submodel of the Snowflake to my Whole House group, so that at any time the prop lights up, only the snowflake nodes will show up and never the whole prop, thus "hiding" the fact its actually a spiderweb :)
    The node ranges are huge, so I've just placed them in a spreadsheet for easy copy+paste functionality.
    https://www.dropbox.com/s/439xes9r9a8390u/spiderflake.xlsx?dl=0


    OzAz and LawrenceDriveLights like this.
  5. The Bald Boy

    The Bald Boy New Elf

    Joined:
    Oct 14, 2018
    Messages:
    31
    Likes Received:
    6
    Location:
    Lake Macquarie
    Wow this awesome!! :thumbsup:

  6. LawrenceDriveLights

    LawrenceDriveLights Full Time Elf

    Joined:
    Jan 16, 2018
    Messages:
    166
    Likes Received:
    193
    Great stuff

    Here is the sub model I did for a spinner for the

    Boscoyo ChromaFlake 24 inch 48 node - 2 Prong (Note the 2 Prong ChromaFlake)

    Product link
    https://www.boscoyostudio.com/index.php?main_page=product_info&cPath=2_31&products_id=57

    Wiring mode as per the xLights import feature ie from here

    View: https://www.dropbox.com/s/74c9dsyoi8jvn6k/xLights%20download%20screenshot%201811208.jpg?dl=0


    Here is a screen shot of submodel

    View: https://www.dropbox.com/s/b00gff1jjz1gei8/ChromaFlake%2024inch%2048%20Node%202%20Prong%20Spinner%20xLights%20Screen%20Shot%2018112018.jpg?dl=0


    Submodel can be downloaded form here
    https://www.dropbox.com/s/8wdawz1ycocdem9/ChromaFlake_2 Prong.xmodel?dl=0

  7. LawrenceDriveLights

    LawrenceDriveLights Full Time Elf

    Joined:
    Jan 16, 2018
    Messages:
    166
    Likes Received:
    193
  8. LawrenceDriveLights

    LawrenceDriveLights Full Time Elf

    Joined:
    Jan 16, 2018
    Messages:
    166
    Likes Received:
    193
    I wonder if this submodel info can be included with the model information when you download the model into xLights (maybe something Boscoyo could add?).
